BioStamp 2C – Máy chấm công và Kiểm soát cửa ra vào sinh trắc học thế hệ mới với sự kết hợp hoàn hảo giữa chất lượng, tính thẩm mỹ và sự đảm bảo của Spectra Spectra Vision, Ấn Độ.
Hệ thống kiểm soát truy cập sinh trắc học BioStamp 2C của Spectra mang lại những lợi ích nhất định trong công nghệ xác thực dấu vân tay. Được thiết kế để cấp quyền truy cập hạn chế vào các khu vực được kiểm soát, thiết bị truy cập bằng dấu vân tay này có thể hỗ trợ nhiều công nghệ thẻ RFID. Dữ liệu có thể sử dụng ngay lập tức cho phép các công ty tăng tốc các quyết định truy cập, do đó cải thiện hiệu suất về thời gian và năng lượng.
Features:
The Ultra Sleek Advantage
This fingerprint door access control device is made up of high aesthetics and an ultra-modern design that helps it get easily installed even directly on the door panels. Its light-grey colour base integrates well with most of the interiors in corporate environments.
Rugged Optical Fingerprint Sensor
Equipped with the most reliable fingerprint matching algorithm, this access control device ensures unrivaled accuracy with the best verification results. Auto-finger update helps in keeping a track of finger changes over the period, thus, registering even dry, wet, and swollen fingers.
Completely Safe & Protected
Designed with IP65 standards of protection, BioStamp 2C is completely protected from dust particles, rainwater, airborne pollutants, and other environmental threats. The device also triggers alarms in case someone tries to fiddle with it.
Multiple RFID Technologies
Supports popular RFID technologies with an inbuilt EM reader and option of having Mifare, HID iClass and HID Prox readers. Fingerprint template can be stored on Mifare card to facilitate data portability & unlimited users.
Unmatched Accuracy for the Best Results
Get the distinct advantage of field-proven authentication technology with the most reliable fingerprint machine for attendance. With the unique auto-finger update feature, get the highest degree of accuracy and speed for authentication.
Field Upgradable Software
Facility to update device software on-site through ethernet interface. The fingerprint door access control device updates can easily be applied without the need of removing device and sending it back to the service center.
Specification:
Basic
- Operating Temp.0 to 50°C
- HumidityRH 5 to 95% Non-Condensing
- Weight290 grams
- Dimensions (mm)H 207 x W 40 x D 42
- Supply Requirement12VDC / 1A Switch mode supply
- PowerLess than 5 watt
Outside
- RTCNon volatile real time clock calendar, Data retention for 10 years without external power
- LED DisplayTri colour LED indication to display verification results
- AudioInbuilt piezo buzzer
- EnclosureIP65 rated weatherproof ABS-PC housing with sleek aesthetics
Inside
- CPU8 bit Microcontroller running at 42 MHz
- Memory4MB Data Flash 32KB RAM
- Finger Print Module533 MHz, 32 bit, Dedicated DSP processor with 256 bit AES fingerprint data encryption
- Finger Print SensorMost rugged and accurate optical fingerprint sensor
- Door SensorOptically isolated input for one door sensor
- Tamper Detect3 axis accelerometer for tamper detection
- WatchdogInbuilt watchdog supervisor
Capabilities
- Template StorageNon volatile memory to store 9000 finger print templates
- Database30,000 user database
- Transactions55,000 Time stamped events storage capacity
Credentials
- ResolutionFingerprint reader with 500 dpi resolution
- EER<0.1%
- Verification Time1:1 match < 0.7 sec, 1:N match < 0.7 sec for less than 1000 fingerprint templates
- Authentication ModeConfigurable mode : Only Finger, Only card, Card + Finger
Communication
- Communication10 Base-T RJ45 ethernet interface (TCP/IP)
- Card Reader SupportInbulit EM reader** (optional Mifare , HID Prox**, HID iClass reader) for 1:1 match
Interface
- Reader InterfaceWeigand configurable from 26 bits to 64 bits/Clock Data
- Lock InterfaceOne potential free changeover relay, contact rating 3A/30VDC
- Aux Reader PortOne reader input port is available for exit weigand or clock/data reader
- Digital InputsOptically isolated one input for exit switch & two general purpose input (GPI)
- Digital OutputsOne general purpose output (GPO) TTL level
